Effective soundproofing for testing heavy construction machinery
Where prototypes of heavy construction machines are put through their paces, things are not always quiet. A noise protection package from FAIST in the Liebherr development center in Kirchberg ensures that the developers in the same building can still do their work in peace and quietness.
Liebherr-Hydraulikbagger GmbH produces around 3,000 excavators a year in Kirchdorf an der Iller, making it one of the world’s leading manufacturers. The company invested around 30 million € in a new development center in 2018. The centerpiece is the 4,500 m² test hall, in which prototypes of new model generations are assembled and tested. Various test stands are available for these tasks – including those with which the stress on the robust machines is specifically tested and which can be correspondingly loud.
The developers of the machines and the associated software are also located in the same building, some directly adjacent. It was therefore necessary to ensure that the noise emissions from the test hall were not transferred to the office wing and also not to the outside, as the hall was located near a residential area. Liebherr wanted the employees to be able to work in the hall itself without hearing protection.
Martin Büche, Head of Testing and Validation at Liebherr in Kirchdorf, quantifies the requirements for sound insulation: “Our goals were: 55dB (A) in the building, 80dB (A) on the test stands and 40dB (A) in the surrounding of the building.”
An acoustic expert determined the necessary noise control measures in advance. He recommended to cover the entire test stand with soundproofing elements on the walls and ceiling. The new building was planned with the costs calculated for this.
A few months later, the shell was in place, the subject of noise protection came into focus and Liebherr was looking for a suitable partner for the implementation. The choice fell on FAIST Anlagenbau – for the following reasons: distinctive expertise, in-house production, best references from test stand construction and a proven supplier at Liebherr. The proximity was also rated positively: Krumbach, FAIST’s headquarters, is only 35 kilometers from Kirchdorf.
After an inspection of the location, the FAIST experts were able to show savings options compared to the expert opinion in a first written statement. René Gums, head of Silence and Acoustic Systems (SAS) business unit at FAIST: “We have demonstrated that significant parts of the noise reduction have already been carried out by the shell and that the recommendations of the report do not have to be fully implemented. Instead, we were able to limit ourselves to what is technically sensible and economically necessary.”
The following measures were implemented: absorbing wall elements on the main surfaces to reduce the reverberation time, cladding of the control room on the test stand, soundproofing windows at the control room, fixed soundproofing walls in production as well as mobile soundproofing walls for acoustic screening of tests.
After installing these soundproofing elements, a FAIST sound measure-ment showed: All requirements are met, no further measures are required. This means that those responsible at Liebherr can be completely satisfied. Martin Büche: “The pragmatic approach was exactly right: It quickly led to the right goal and we also achieved savings in the six-digit range.” He describes the result from a subjective point of view: “When I’m in the office, I hardly hear the noise from the test stands.”
As a special “extra”, a new development from FAIST was implemented: an LCD screen at a test stand, which is connected to a continuous sound measurement and shows the mandatory sign “wear hearing protection” as soon as 80dB (A) are exceeded. This is hearing protection “on demand”.
